The First AI Governance Appliance EQ760 Series I
EQTY's Governance Appliance EQ760 Series I enables enterprises to bring the power of Verifiable Compute to govern AI workflows directly on premise, in the field, or anywhere they are needed.
High Performance Verifiable AI
Configured to pair both 5th Gen Intel® Xeon® E5 Series Processors with NVIDIA H100/200 Processors. Allows you to leverage state-of-the-art AI processing with new layers of trust and security from EQTY's groundbreaking AI Notary system.
Read White Paper

The EQ760 is a fit-for-purpose, security-first appliance with an onboard Hardware Security Module and advanced cryptography services to both authenticate and protect your workflows at scale.

Bundled with EQTY's Governance Studio, you can easily provision cryptographic keys and AI certificates that allow fortamperproof, persistent, and verifiable responsible AI compliance.

Secured with Intel® Trust Domain Extensions and NVIDIA Confidential Computing with attestations. A new hardware root of trust for AI.

Always On

Simple Install

Easy Maintenance

Technical Specifications
Security
  • Intel® Trust Domain Extensions (Intel® TDX) and NVIDIA Confidential Computing with attestations.
  • Cryptographically-signed
  • Secure Boot
  • Secure Erase
  • Silicon Root of Trust
  • System Lockdown (requires iDRAC9 Enterprise or Datacenter)
  • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
  • Secured Component Verification (Hardware integrity check)
  • Data at Rest Encryption (SEDs with local or external key management)
GPU
  • 1x NVIDIA H100 Tensor Core GPU with 80GB of GPU RAM
CPU
  • 1x Intel Xeon Silver 4514 Processor with 16 cores 2.00 GHz (Base) 3.40 GHz (Max Boost)
Operating System
  • OS: Ubuntu 24.04
  • Linux Kernel version: 6.9
Memory
  • 64GB RDIMM, 4800MT/s Dual Rank

Up to:

Memory Module Slots

  • 32 DDR5 DIMM slots

DIMM Speed

  • Up to 5600 MT/s on the 5th Generation Intel® Xeon Scalable processors

Maximum RAM

  • RDIMM 8 TB
Storage
  • 960 GB Data Center NVMe Read Intensive AG Drive U2 Gen4 wtih carrier
Networking

Network Options

  • 2 x 1GbE LOM card (optional)
  • 1 x OCP card 3.0 (optional)
  • Note: The system allows either LOM card or an OCP card or both to be installed in the system.

Front Ports

  • 1 x iDRAC Direct (Micro-AB USB) port
  • 1 x USB 2.0
  • 1 x VGA

Rear Ports

  • 1 x Dedicated iDRAC Ethernet port
  • 1 x USB 2.0
  • 1 x USB 3.0
  • 1 x Serial (optional)
  • 1 x VGA (optional for Direct Liquid Cooling configuration)
Dimensions
  • Height – 86.8 mm (3.41 inches)
  • Width – 482 mm (18.97 inches)
  • Depth – 772.13 mm (30.39 inches) with bezel 758.29 mm (29.85 inches) without bezel
Form Factor
  • 2U rack server
  • Temperature

    Temperature range for altitudes <= 900 m (<= 2953 ft)

    • 5–40°C (41–104°F) with no direct sunlight on the equipment

    Humidity percent range

    • 8% RH with -12°C (10.4°F) minimum dew point to 85% RH with 24°C (75.2°F) maximum dew point
    Power Supply
    • Dual, Hot Plug, Power Supply (1+1) Redundant 1400W
    RAID

    External Controllers

    • HBA355e, PERC H965e

    Software RAID S160

    • S160
